Copper-tungsten disc W70Cu30 (machined)
Machined discs in WCu 70/30 tungsten-copper, bores to H7 fit.
Article numberRD-WCu30-150x30x5
Preis auf Anfrage
On request
Add quickly:
Main price net, plus VAT. Purchase on invoice after registration.
All sizes and prices
Material info
Key properties
- Composition: 68–72 % W, 28–32 % Cu, additives < 0.6 %
- Density: 14.0–14.4 g/cm³
- Electrical conductivity: 42–44 % IACS
- Thermal conductivity: 160–180 W/mK
- Hardness: 180–220 HV10, tensile strength 440–550 MPa
- Thermal expansion: 10.8 × 10⁻⁶/K
Applications
- Electrodes for die-sinking EDM
- Electrodes for resistance welding
- Contact material for electrical equipment and high-voltage switches
- Mass balancing
Show technical notesHide technical notes
Complies with ASTM B702 and DIN EN ISO 5182. Inspection document to EN 10204 – test report 2.2 or inspection certificate 3.1 – on request.
Technical data
- Article no.
- RD-WCu30-150x30x5
- Material
- WCu70_30
- Diameter
- 150 mm
- Thickness
- 5 mm
Datasheets
Description
Tungsten-copper is made by powder metallurgy: a pressed tungsten skeleton is infiltrated with copper. The tungsten provides hardness and temperature resistance, the copper electrical and thermal conductivity. With 30 % copper, WCu 70/30 is the most conductive of the three standard grades. The discs are machined ready for installation; other dimensions are made to drawing.
